Putytė ir dar daug kitų keistų žodžių...

Tikiu į Yamahą

Šitas corona imtuvas Corona Dual Conversion 6CH Receiver RD620II 35mhz yra su kvarcais

Size 36.8*22*8.3mm
Weight 8.2g(with shrink wrap)
Sensitivity about 2.0µV
Selectivity ±8kHz at 65dB down
Number of channels 1-6
Filtering Dual turned RF circuitry
Filtering Dual 4 element ceramic filter
Filtering DSP filtering in MCU with mild algorithm
Shift polarity positive or negative (auto-detect)
Modulate FM/PPM(pulse position modulation)
Case Shrink wrap
Operating Voltage 4.8V~6.0VDC
Operating Current 11mA

Dual Conversion Receiver
Type Range Filtering Crystal Size Intermediate Frequency IP3
RD620II >1,5 Km DSP HC-50 10.7MHz +10dBm
RD820II >1.5Km DSP HC-50 10.7MHz +10dBm

_________________
Aukstasparnis putinukas
Homemade RC tank
HPI MT2
Quadrocopter
-------------------------------------------------------
Amžius 33m.

O šis yra be kvarcu

RP6D1 6ch 35MHz Dual Conversion Receiver
Despite the small size, the receiving range reaches as far 1 mile

Specifications:
Dimensions 48.5 x 20.8 x 12mm
Frequency FM 35 MHz
No. of Channel 6ch
Sensitivity better than 2.0uV
Selectivity 8kHz at 65bB down
RF technology Dual tuned RF circuitry
Analog filtering Dual 4 pole ceramic filter
Digital filtering DSP filtering with mild algorithm
Modulation FM/PPM
Shift polarity Positive or Negative (auto detect)
Case Shrink wrap
Operating Voltage 4.8 - 6V DC
Operating Current 26mA.
